• Professional right-angle 6.35 mm (¼″) mono plug
• Designed for instrument, stage, and audio cabling applications
• Rugged zinc alloy housing with nickel plating for durability
• Compact, slim design for tight spaces and pedalboards
• Engineered to meet international EIA/IEC standards
• Typcal use for:
  • Musical Instruments: Commonly used for guitars, basses, keyboards, and other electric instruments
  • Patch Cables: Ideal for pedalboards where space is limited due to the right-angle design
  • Audio Equipment: Connections between amplifiers, mixers, effects units, and speakers
  • Stage & Studio: Professional audio cabling in live sound setups and recording environments
  • DIY / Custom Cables: Favored by technicians and musicians for building durable, high-quality cables

Features

• Right-angle TS (Tip-Sleeve) mono plug
• Nickel-plated contacts for reliable signal transfer
• Nickel-plated zinc alloy shell for robust protection
• Ergonomic body design with secure grip surface
• Integrated rubber strain-relief sleeve to protect cables
• High mechanical strength with brass inner tube (0.4 mm thick)
• Easy solder termination for custom cable assembly
• Patent-protected design for stability and performance

Specifications

• Connector Type: 6.3 mm (¼″) mono right-angle TS plug
• Contacts: Brass with nickel plating
• Housing: Die-cast zinc alloy, nickel finish
• Bushing: PA (polyamide) with 30% glass fiber
• Shell Finish: Nickel-plated
• Cable Entry: With rubber sleeve for strain relief
• Compliance: EIA / IEC standards
• Applications: Guitar/bass cables, patch leads, pro-audio setups, stage/studio gear

What's in the box

• 1 x 6.35mm Right Angle Mono Jack Nickel Contacts & Nickel Shell
