• Compact and versatile 10-channel analog audio mixer with USB audio interface
• Designed for home studios, podcasting, streaming, small bands, and live sound
• Includes built-in 56 DSP effects (reverb, delay, chorus, etc.)
• Lightweight and portable with rugged metal chassis
• Ideal for microphone + instrument + playback combination setups

Features

• 10 input channels (2 mono + 4 stereo pairs)
• 2 XLR mic inputs with mic preamps and +48V phantom power
• 56 onboard digital effects with FX send per channel
• Built-in USB audio interface for PC/Mac playback/recording
• 3-band EQ on each mono channel (High/Mid/Low)
• FX send and AUX routing
• Stereo main output + control room/headphone output
• Peak LEDs & gain trims on inputs
• Compact footprint for mobile rig or desktop use
• Plug-and-play USB – no drivers needed

Specifications

• Channels: 10
• 2 x XLR, 10 x 6.3 mm jack
• Outputs: 4 x 6.3 mm jack
• FX: 56 FX Logic Acoustic Modelling FX:Room, Plate, Hall and Gated Reverb. Chorus, Flanger, Rotary Speaker, Delay
• Headphone Output: 6.3 mm jack
• EQ: 3-Band
• Phantom Power: Yes
• USB: 16 bit / 48 KHz
• Signal To Noise Ratio: >78 dB ±5 dB @ Max Gain
• Frequency Response: 20 Hz-20 KHz ±1 dB
• Display: Dual 4-Segment LED, FX Setting Display
• Dimensions: 293.9 x 183.8 x 52.8 mm
• Weight: 1.37 kg

What's in the box

• 1 x Wharfedale Connect 802USB Mixer
• 1 x Power Supply
• 1 x Owners Manual
