• The DM 118 Sub features an ultra-reliable power section that provides a total of 800 watts of peak available power with DDT compression.\
• This powered enclosure also features an 18″ heavy-duty woofer with a 3″ voice coil.
• The DM 118 Sub provides a balanced input via a combination jack that accepts balanced TRS 1/4″ input as well as a balanced XLR input.
• There are two balanced thru high pass XLR outputs, and a full-range XLR output.
• There is an adjustable Level control, as well as a combination LED indicator, that illuminates when power is on and when the “soft-limiting” DDT circuit is activated.

Features

• Vented bass powered subwoofer enclosures

• Power amp has forced air cooling for maximum reliability

• Internal line level low-pass/high-pass crossover network

• XLR/1/4 combo jack input

• Two high-pass XLR outputs, and one full-range thru XLR output

• Ground lift switch for lifting cable shield from ground

• Full-coverage heavy-duty perforated steel grill

• Fully adjustable Kosmos® C for increased bass impact

• Steel handles

• Compact dimensions for an 18″ woofer based sub

• 18″ premium heavy-duty woofer

• Threaded pole mount with speaker pole included

• 800 watts peak available power

• Large heavy-duty locking caster with damped bearings

• Polarity switch for polarity reversal of subwoofer

Specifications

• Type: 18″ powered subwoofer (active)

• Woofer: 18″ heavy-duty driver with 3″ voice coil

• Power output:

  • 800 W peak

  • ~400 W continuous

• Frequency response: 38 Hz – 180 Hz (-10 dB)

• Max SPL: Approx. 126 dB peak

• Built-in DSP: Includes Peavey Kosmos® bass enhancement

• Inputs:

  • Combo XLR / 1/4″ TRS balanced input

• Outputs:

  • Two high-pass XLR outputs

  • One full-range XLR thru output

• Controls:

  • Level control

  • Polarity (phase) switch

  • Ground lift

• Cooling: Fan-cooled amplifier

• Enclosure: Rugged plywood cabinet with steel grille

• Mobility: Built-in casters & side handles

• Weight: Approximately 42 kg (92 lbs)

• Dimensions (approx.):

  • Height: 28.8″ (732 mm)

  • Width: 20.5″ (521 mm)

  • Depth: 27.1″ (688 mm)

What's in the box

• Peavey DM‑118 SUB powered subwoofer cabinet

• Threaded pole-mount kit (pole included)

• IEC power cord

• Quick-start guide / safety manual
