• True diversity UHF wireless microphone system with up to 4 programmable channels
• Sync functionality allows setting of frequency, EQ, transmission power, and display colour
• Supplied with bodypack transmitters and lapel microphones for hands-free use
• Supports neckband and lavalier microphone options
• Rack-mountable receiver with flexible antenna positioning
• Designed for conferences, stage use, theatres, and presentations

Features

• Independent 7-band EQ per channel
• True diversity system with internal antenna distribution
• Auto frequency scan/sweep function
• Individual XLR outputs + mixed jack output
• Licence-free operation (863–865MHz)
• Additional 823–832MHz band support (license required)
• Wireless IR sync between receiver and transmitters
• Full-colour display with rotary control

Specifications

• Receiver
  • Dimensions: 482 × 185 × 44 mm (1U)
  • Weight: 1.513 kg
• Bodypack Transmitter
  • Dimensions: 90 × 60 × 25 mm
  • Weight: 74 g (excluding battery)
• Neckband Microphone
  • Dimensions: 180 × 140 × 60 mm
  • Weight: 28 g
• Lavalier (Lapel) Microphone
  • Dimensions: 27 × 12 mm Ø
  • Weight: 23 g
• General
  • Power Supply: 12–18V DC, 1000mA (adapter included)
  • Batteries: 2 × AA per channel
  • Carrier Frequencies: 823–832 MHz / 863–865 MHz
  • Wireless Range: Up to 60 m
  • Antenna Connection: 2 × BNC

What's in the box

• 1 × Quad channel wireless receiver
• 4 × Bodypack transmitters
• 4 × Lavalier microphones
• 4 × Neckband microphones
• 2 × Antennas
• 2 × BNC extension leads
• 1 × Power adaptor
• Rack mount accessories
• User manual
