Features

• Balanced tonality ideal for 2-way speakers
• High efficiency
• Water resistant paper cone

• Optimized parameters for compact cabinets

Specifications

• General
  • Nominal diameter: 380mm (15 inch)
  • Nominal Impedance: 8Ω
  • Power handling: 500W RMS (AES Standard)
  • Sensitivity: 98dB / 1W / 1m
  • Voice coil diameter: 3 inch (75mm)
  • Voice coil height Hvc: 21mm
  • Voice coil air gap Hag: 9mm
  • Xmax (Hvc-Hag)/2 + Hag/4: ±8.25mm

  • Xmech (peak-peak): 44mm

  • Voice coil winding: 2 layers IN / OUT

  • Voice coil material: 240°C Thermal Class CCAW

  • Voice coil former: BAF fiberglass

  • Suspension: Triple roll, impregnated fabric

  • Spider: single, cold formed NOMEX®

  • Cone: fiber loaded waterproof treated paper

  • Chassis: Die Cast Aluminum

  • Magnet: Ø190mm Y30 Ferrite
• MOUNTING & SHIPPING
  • Overall diameter: 400mm

  • Bolt circle diameter: 378mm (8*M5)

  • Baffle cutout diameter: 353mm

  • Flange and gasket thickness: 10mm

  • Overall depth: 164mm

  • Net weight: 7.5kg

  • Shipping weight: 9kg

  • Shipping box 420x380x210mm
• T&S PARAMETERS
  • F(s): 45Hz
  • Q(ms): 7.228
  • V(as): 131ℓ

  • M(ms): 105g

  • R(ms): 6.92kg/s

  • S(d): 881cm²

  • V(d): 0.705ℓ

  • R(e): 5.78Ω

  • Q(es): 0.491

  • C(ms): 0.119mm/N

  • Q(ts): 0.46

  • L(e) 1kHz: 1.08mH

  • BL: 18.5

  • n(0): 2.3%

What's in the box

• 1 x Replacement Speaker
