Keyboard: 76 keys (piano-style)
Touch Response: 2 sensitivity levels, Off
Sound Source: AHL (Dual-element)
Maximum Polyphony: 48
Tones: 700 built-in tones (10 user tones)
Layer/Split: Layer, Split (variable split point)
Digital Effects:
Reverb: 10 types
Chorus: 5 types (not simultaneous with DSP)
DSP: 100 preset, 100 user (not simultaneous with Chorus)
EQ: 5 types (Off, Soft, Bright, B.Boost, Powerful)
Auto Harmonize: 12
Arpeggiator: 150 types
Rhythms/Patterns: 210 built-in rhythms (10 user rhythms)
Auto Accompaniment:
Modes: CASIO Chord, Fingered 1, Fingered 2 (6th off), Fingered 3 (on bass), Full Range Chord
Controllers: Start/Stop, Intro, Normal/Fill-in, Variation/Fill-in, Synchro/Ending
Built-in Songs: 5 demo tunes
Metronome:
Beats: 0, 2, 3, 4, 5, 6
Tempo range: quarter note = 30 to 255
Recorder (Song Sequencer):
16 multi tracks + 1 system track
5 songs, approx. 12,000 total notes
Supports real-time recording, step recording, song edit, track edit, event edit
Other Functions:
Mixer: 32 channels + EXT IN (MIC IN)
Rhythm editor: 10 user rhythms
Tone editor: 10 user tones
Registrations: 32 setups (4 sets x 8 banks)
Music preset: 305 preset with chord progression, chord edit (50 user presets)
One-touch preset: 210 sets
Arpeggiator: 150 types
Temperaments (scales): Equal temperament + 16 types / scale fine tune
Octave shift: ±2 octaves
Rhythm/song controller
Pitch bend wheel: 0 to 24 semitones
Large Dial
Key Transpose: ±1 (-12 to +12 semitones)
Tuning Control: A4 = 415.5 - 440.0 - 465.9 Hz
Pedals: Standard jack (sustain, soft, sostenuto, start/stop)
Display Screen: LCD with backlight
USB Memory / SD Memory:
Supports up to 32GB SD/SDHC cards
Functions: SMF playback (up to 320KB per file), file save/load/delete, card format
Save/load: Registrations, user rhythms, user tones, user DSPs, user music presets, sequencer songs
MIDI: GM Level1 compatible, USB terminal
Speakers: 12cm x 2 + 3cm x 2, bass-reflex system
Amplifier Output: 6W + 6W
Input/Output Terminals:
Mic in
Audio in
Line output (L/MONO, R)
Headphones (standard stereo jack)
Sustain/assignable
USB type B
External power (12V DC)
Note: USB cable (A-B type) required for computer connection
Power Requirements:
Batteries: D-size x6
AC adaptor: AD-A12150LW
Vendor | Casio |
---|---|
Type | Keyboards/Pianos/Accessories |
Sku | 31500066 |
Barcode | 4971850314134 |
Weight: | 7.0 kg |
