ITC TI-120 Mixer Amplifier 120W RMS 100V with Phone Jack and MIC Input

R 3,299.00R 3,999.00 18
Quantity:
Sku: 64251120
Visa Mastercard American Express Ozow MTN Mobile Money

  • The basic public address mixer amplifiers have power ratings from 60W, 120W, 240W, 350W, 500W to 650W.
  • They are featured of 3 microphone inputs, 2 aux inputs and 1 EMC input.
  • Priority muting is achieved via EMC for overriding other inputs except Mic1 on front panel.
  • Individual gain controls are provided for Mic 1-3 and Aux 1-2, bass and treble controls and master volume control are provided for overall tone control. 70V, 100V and low impedance 4-16 ohms speaker outputs are provided. Extensive protection from short-circuit, overload and high temperature.
Features
  • Mixer amplifier for paging and background music system
  • Rated power from 60W, 120W, 240W, 350W, 500W to 650W
  • 2U rack mount (less than 350W) and 3U rack mount design
  • 70V, 100V and low impedance 4-16ohm speaker output
  • Three Mic inputs by phone jack type
  • Mic 1 with VOX priority and VOX level on front panel
  • Mic 2-3 by phone jack on rear panel
  • Two Aux Inputs and 2 line inputs for spare use
  • One EMC priority input
  • EMC has priority over all inputs except MIC1
  • Mic 1-3, Aux 1-2 and master volume controls and bas
Specifications
  • Model: T-120

  • Rated Power Output: 120W

  • Speaker Outputs: 70V, 100V & 4~16Ω

  • Input Sensitivity & Impedance:

    • MIC 1, 2, 3: 5mV/600Ω, Unbalanced phone jack input

    • MIC 2, 3: 775mV/10KΩ, Unbalanced RCA input

    • AUX 1, 2: 350mV/10KΩ, Unbalanced RCA input

    • EMC: 775mV/10KΩ, Unbalanced RCA input

  • Output Sensitivity & Impedance:

    • MIX OUT: 1V/470Ω, Unbalanced RCA output

  • Tone Control:

    • Bass: ±10dB at 100Hz

    • Treble: ±10dB at 10KHz

  • Frequency Response: 50Hz~16KHz (±3dB)

  • S/N Ratio:

    • MIC 1, 2, 3: ≥66dB

    • AUX 1, 2: ≥80dB

  • THD: Less than 0.5% at 1KHz, 1/3 rated power

  • Muting Function:

    • MIC 1 overrides other input signals with 0-30dB attenuation

  • Crosstalk: <50dB

  • Cooling:

    • Fan automatically starts when temperature reaches 55℃

  • Protection:

    • High temperature, overload & short-circuit

  • Power Supply:

    • ~110V/60Hz or ~230V/50Hz or DC 24V

  • Power Consumption: 200W

  • Weight: 9.3kg

  • Dimensions: 484×335×88mm

  • Finish:

    • Panel: aluminum plate, black

    • Case: steel plate, black

What's in the box
  • 1 x Mixer Amplifier
  • 1 x Power Cable
  • 1 x Manual
Vendor ITC
Type PA Amplifiers
Sku 64251120
Weight:  10.0 kg
